IMB-1238

The IMB-1238 is a high-performance industrial Mini-ITX motherboard built on the Intel® Q670 chipset, supporting Intel® 14th/13th/12th Gen (Raptor Lake-S Refresh / Raptor Lake-S / Alder Lake-S) Core™ processors up to 65W. It accommodates up to 96GB DDR5 4800/5600MHz via two SO-DIMM slots and offers quad display support via 1x HDMI 2.0b, 1x HDMI 1.4b, 1x DisplayPort 1.4a, and LVDS/eDP.

Expansion options include 1x PCIe x16 (Gen5, riser-capable), 1x M.2 Key E (for Wi-Fi), 2x M.2 Key M (PCIe Gen4 x4 & PCIe Gen3 x4/SATA3), and 1x M.2 Key B (with SIM slot for 4G/5G). Networking features dual Intel® LAN (1x 2.5GbE, 1x 1GbE with vPro). Rich connectivity includes 4x USB 3.2 Gen2, 2x USB 3.2 Gen1, 4x USB 2.0, 4 COM ports, 4 SATA3, GPIO, Intel® VMD RAID 0/1/5/10, and onboard TPM 2.0. Designed for rugged industrial use, it operates from -20°C to 70°C with ATX PWR or 12V DC-in.
